The chiller is compact and can be easily connected to existing piping systems. It is equipped with a water or glycol tank and a circulation pump. At outlet temperatures below +10°C, an antifreeze agent (propylene glycol approx. 30%) is required. The device is additionally equipped with an electric heater - the ability to heat the tanks. The price of the device includes a set to prevent the chiller from overflowing.
Compact water cooler AquaZero 12.0 kW:
- Cooling water temperature range from: -5°C* to +15°C
- Ambient temperature range from: +5°C to +42°C
- Cooling capacity: 12.00 kW
- Refrigerant: R407C
- In accordance with F-Gas Regulation (EU) No. 517/2014, up to 13.5 kW, NO leak test required**
- Power supply: 400 V, 3-phase, 50 Hz
- Connection cable: 4 meters with plug
- Water inlet/outlet connection: 3/4" external thread
- Water/glycol tank capacity: 160 liters
- Included Bypass valve, pressure gauge, strainer, water shortage float switch
- Dimensions: L 880 x H 1600 x D 750 mm
- Weight: 250 kg without water and additional options
ADVANTAGES:
- 4 meter connection cable with plug
- Strainer installed in the water supply
- Bypass with a pressure gauge installed in the device
- Float switch installed for low water level alarm
- Digital display
- MicroGroove condenser (microchannel filter, sensitive to contamination)
- A series for min. outlet temperature -5 ° C.
